Waddah Attar Explosion

In short: the Waddah Attar Explosion for MetaTrader 5 combines MACD-based momentum, a volatility “explosion” line and a dead-zone filter, and only signals when trend strength, volatility expansion and market activity line up.

When to use it

• Breakout trading: confirm that a breakout has real momentum and volatility behind it.
• Avoiding dead markets: the dead-zone filter keeps you out of low-activity conditions.
• Automation: it uses indicator buffers only, so an EA can read every value.

How it differs

A MACD alone shows momentum but not whether the market is active enough to follow through. Waddah Attar adds a standard-deviation explosion line and a range-based dead zone, so a momentum bar only counts when volatility is expanding above the noise level.

Getting started

1. Attach it to a chart; it runs in a separate window.
2. Read the histogram colors: increasing or weakening bullish and bearish momentum.
3. Only act when the histogram is above both the explosion line and the dead zone.
4. Adjust the Sensitivity setting to make momentum changes more or less pronounced.

For a full walkthrough, read why your breakouts keep failing and how Waddah Attar helps.

Frequently asked questions

What is the dead zone?

A minimum activity level based on market range. Momentum below it is treated as noise.

Can an EA use it?

Yes. It is built with indicator buffers only, so it is fully compatible with Expert Advisors.

Is there a free demo?

Yes. You can download a free demo from the MQL5 Market and run it in the MetaTrader 5 Strategy Tester before buying.

Full product description

Waddah Attar Explosion is a momentum and volatility–based indicator designed to highlight periods of strong market movement while filtering out low-activity conditions.

The indicator combines:

• MACD-based momentum acceleration

• Volatility expansion using standard deviation

• A dynamic dead-zone filter based on market range

Signals are generated only when trend strength, volatility expansion, and market activity align, helping traders focus on higher-quality market conditions.

The indicator runs in a separate window and uses indicator buffers only, ensuring high performance and full compatibility with Expert Advisors.

Core Logic Explained

Trend Momentum

Trend strength is calculated using the difference between a fast and slow exponential moving average (MACD logic).
The change in MACD value is amplified by a Sensitivity parameter to measure momentum acceleration.

Momentum is displayed as a color-coded histogram:

• Bullish momentum increasing

• Bullish momentum weakening

• Bearish momentum increasing

• Bearish momentum weakening

This allows visual assessment of both direction and strength.

Explosion (Volatility Expansion)

Volatility is measured using standard deviation over a configurable channel length, similar to a Bollinger-style volatility model.

The Explosion line rises when volatility expands, indicating increased market activity.

Dead Zone Filter

To avoid low-energy or sideways markets, a Dead Zone is calculated using a smoothed average of the true range.

When volatility remains below this level, signals are filtered out.

Buy & Sell Signals

Buy and sell arrows are generated only when all conditions are met:

• Momentum direction is clear

• Trend strength exceeds volatility

• Volatility is expanding

• Market activity is above the Dead Zone

This multi-condition logic helps reduce false signals during consolidation.

Visual Elements

• Color-coded momentum histogram

• Explosion (volatility) line

• Dead Zone filter line

• Buy and Sell arrow signals

• Separate indicator window for clarity

All visuals are drawn using indicator buffers only.

Alerts & Notifications

The indicator includes optional real-time alerts:

• Popup alerts on buy and sell signals

• Optional push notifications to mobile devices

Alerts are triggered only on confirmed signals.

Built-in Signal Tester

An optional on-chart signal tester is included for analytical purposes:

• Simulates historical buy and sell signals

• Uses user-defined take-profit and stop-loss points

• Displays total trades, winning trades, and win rate directly on the chart

This feature is intended for signal evaluation only and does not represent real trading performance.

Customization Options

• Momentum sensitivity

• Fast and slow EMA lengths

• Volatility channel length and multiplier

• Light or dark chart theme

• Alert and notification settings

• Tester parameters (TP, SL, start date)

Compatibility

• Works on all symbols supported by MetaTrader 5

• Compatible with all timeframes

• EA-friendly (buffer-based output only)

• No repainting of alerts after signal formation

Disclaimer

This indicator is provided for educational and analytical purposes only.
It does not provide investment advice and does not guarantee trading results.
